[Nhcoll-l] Ink for priting labels for fluid preserved specimens

[Dirk Neumann]

Dear Joosep,

there is a very good overview on this topic on the SPNHC WIKI pages
<https://spnhc.biowikifarm.net/wiki/Labeling_Natural_History_Collections>,
but there is no easy straight forward answer to this question, because
"printing" always is a combination of printing medium, printing method
and the printer itself and thus a lot a variables that influence your
result, i.e. the label that is placed in the jar.

Sadly, printers and required inks and toners change constantly and at
high rate. Parts of our collections for example still use the good old
HP600 monochrome fossils, but HP decided to finally end the production
of the ink cartridges. So it would be good to have an eye on
'availability' (how long have specific printers been on the market, how
likely is it that they will still be supported in 20 years from now).

In your case, I would look into inkjet printer that use a system similar
to that of the old HP printer, which boil up the ink and shoot them into
the paper, so that the pigments of the ink penetrate into the pulp of
the paper and not only sit on the covering layer. This improves abrasion
resistance of the imprint.

The are quite a few inkjet printers that are rated to produce permanent
/archival-quality prints, i.e. these printers should use a high quality
pigment ink. But it might be worth checking available details of the ink
and the printing method. I once tested durability of labels by putting
specimens (field tags and gill tags) into a  PE-bottle and put it in a
washing machine for a full cold washing programme to see of gill tags
would stay in place and test tables for abrasion resistance before we
left for field work on extremely bumpy roads in Africa ...

Hope this helps,
Dirk





Am 01.09.2021 um 09:48 schrieb Joosep Sarapuu:
>
> Hi,
>
> Just in case I also add here the paper we are using these days:
>
> Resistall paper Sheets 584 x 457mm
> (https://www.preservationequipment.com/Catalogue/Conservation-Materials/Paper-Board/Herbarium/Resistall-Paper-Byron-Weston-Co-Strong-when-wet
> <https://www.preservationequipment.com/Catalogue/Conservation-Materials/Paper-Board/Herbarium/Resistall-Paper-Byron-Weston-Co-Strong-when-wet>)
>
> Sincerely,
>
> Joosep
>
> *From:*Nhcoll-l [mailto:nhcoll-l-bounces at mailman.yale.edu] *On Behalf
> Of *Joosep Sarapuu
> *Sent:* Wednesday, September 1, 2021 10:37 AM
> *To:* nhcoll-l at mailman.yale.edu
> *Subject:* [Nhcoll-l] Ink for priting labels for fluid preserved specimens
>
> Dear colleagues,
>
> We are currently holding our zoology fluid-preserved specimens in
> 70-75% EtOH (or trying to change old fluid to this). And of course we
> would like to print out the labels for them (to put them inside the
> jar). What kind of ink we have to use to print these labels and be
> sure that the labels last well?
>
> Sincerely,
>
> Joosep Sarapuu
>
> Estonian Museum of Natural History
>
>
> _______________________________________________
> Nhcoll-l mailing list
> Nhcoll-l at mailman.yale.edu
> https://mailman.yale.edu/mailman/listinfo/nhcoll-l
>
> _______________________________________________
> NHCOLL-L is brought to you by the Society for the Preservation of
> Natural History Collections (SPNHC), an international society whose
> mission is to improve the preservation, conservation and management of
> natural history collections to ensure their continuing value to
> society. See http://www.spnhc.org for membership information.
> Advertising on NH-COLL-L is inappropriate.


--
