[Nhcoll-l] [EXT]Re: [EXTERN] Microscope slide storage

Thu Feb 15 13:08:51 EST 2024

I will chime in and say I also love those giant Delta design slide
cabinets. They custom make everything so you can get the trays to hold
whatever you need. I will comment that the "label holders" they put on the
front of the trays are useless - notably because they don't hold paper
well, and at the scale of a massive cabinet you can't read the labels above
or below a certain height. Next time I order a cabinet I would have these
done away with and have a simple smooth faced tray with a central pull tab.
I've been using a label maker with adhesive labels which hold up great. I
would also love it if they could design the trays to be slightly stackable
- or at least not as precarious as they are now. You definitely can not
transport two trays on top of eachother.

Christopher C. Grinter
Collection Manager of Entomology
Secretary, The Lepidopterists’ Society
Subject Editor: Lepidoptera, The Pacific Coast Entomological Society
California Academy of Sciences
55 Music Concourse Dr
San Francisco, CA 94118
T 415.379.5320
We regenerate the natural world through science, learning, and
collaboration.
Learn more at calacademy.org <http://www.calacademy.org/>
<https://www.instagram.com/calacademy/>

On Thu, Feb 15, 2024 at 8:27 AM Meier, Gretchen <meierga at miamioh.edu> wrote:

> Thank you for this discussion, now I know what to do with my errant
> 20,000+ slides!
>
> On Thu, Feb 15, 2024 at 11:24 AM Lazo-Wasem, Eric <
> eric.lazo-wasem at yale.edu> wrote:
>
>> Here we use two sizes that we are very please with, Manufactured by Delta
>> Designs. We have 27 single door (lockable) cubes that each have 80 trays
>> for a total 1200 slide capacity; these were a standard design suggested by
>> Delta.  Most of these are sitting  on three tiers of pallet racking; should
>> anyone want a picture let me know.
>>
>>  We also had more or less customized "student" cabinets that have 25
>> trays for a total capacity of 500 slides.  These are ideal for temporary
>> storage of slides being used or made by students, visitors, etc. and are
>> easy to move to different workstations.
>>
>> Eric A. Lazo-Wasem, Senior Collections Manager
>>
>> Division of Invertebrate Zoology
>>
>> Peabody Museum of Natural History
>>
>> Yale University
>>
>> 170 Whitney Avenue
>>
>> New Haven, CT 06520
>>
>> (203) 432-3784
>> ------------------------------
>> *From:* Nhcoll-l <nhcoll-l-bounces at mailman.yale.edu> on behalf of
>> Jean-Marc Gagnon <JMGAGNON at nature.ca>
>> *Sent:* Thursday, February 15, 2024 11:10 AM
>> *To:* Sagebiel, J. Chris <sagebiel at austin.utexas.edu>; Dirk Neumann <
>> d.neumann at leibniz-lib.de>; nhcoll-l at mailman.yale.edu <
>> nhcoll-l at mailman.yale.edu>
>> *Subject:* Re: [Nhcoll-l] [EXT]Re: [EXTERN] Microscope slide storage
>>
>>
>> Chris,
>>
>> I would suggest contacting Delta to find out what they can do.
>>
>> I suspect they can adjust their cutters to different sizes, but I am not
>> certain.
>>
>> Jean-Marc
>>
>>
>>
>> *From:* Sagebiel, J. Chris <sagebiel at austin.utexas.edu>
>> *Sent:* Thursday, February 15, 2024 11:00 AM
>> *To:* Jean-Marc Gagnon <JMGAGNON at nature.ca>; Dirk Neumann <
>> d.neumann at leibniz-lib.de>; nhcoll-l at mailman.yale.edu
>> *Subject:* RE: [Nhcoll-l] [EXT]Re: [EXTERN] Microscope slide storage
>>
>>
>>
>> Are these cabinets useful for odd-sized slides?  I have a decent size
>> collection of histological slides that are often wider than standard
>> microscope slides. I cannot tell from the website photos whether large
>> slides can be fit into these trays – do the tabs on the trays fold down or
>> can they be removed?
>>
>>
>>
>> Thanks!
>>
>>
>>
>> J. Chris Sagebiel, collections manager
>>
>> Texas Vertebrate Paleontology Collections
>>
>>
>>
>> *From:* Nhcoll-l <nhcoll-l-bounces at mailman.yale.edu> *On Behalf Of *Jean-Marc
>> Gagnon
>> *Sent:* Thursday, February 15, 2024 9:44 AM
>> *To:* Dirk Neumann <d.neumann at leibniz-lib.de>; nhcoll-l at mailman.yale.edu
>> *Subject:* Re: [Nhcoll-l] [EXT]Re: [EXTERN] Microscope slide storage
>>
>>
>>
>> Dirk,
>>
>> I meant to check; thanks for the prompt.
>>
>> The version we have has 604 trays, each holding 72 regular microscope
>> slides, for a total of 43 488 slides.
>>
>> I know that this tray version was an improvement from the previous, so
>> they may have found a way to increase the number of slides stored per tray
>> and per cabinets.
>>
>> Cheers,
>>
>> Jean-Marc
>>
>>
>>
>> *From:* Dirk Neumann <d.neumann at leibniz-lib.de>
>> *Sent:* Thursday, February 15, 2024 10:36 AM
>> *To:* Jean-Marc Gagnon <JMGAGNON at nature.ca>; nhcoll-l at mailman.yale.edu
>> *Subject:* Re: [EXT]Re: [Nhcoll-l] [EXTERN] Microscope slide storage
>>
>>
>>
>> Hi Jean-Marc,
>>
>>
>>
>> ... if I am not wrong, it can hold up to 56K slides (depending on the
>> size of the slides) ...
>>
>>
>>
>> With best wishes
>>
>> Dirk
>>
>>
>>
>>
>>
>> Am 15.02.2024 um 16:19 schrieb Jean-Marc Gagnon:
>>
>> Vanessa,
>>
>> After seeing the large, two-door Delta Slide Cabinet in use at the Denver
>> Museum of Nature & Science in 2017, we obtained one in 2018-19 and we are
>> very satisfied with it. It can house in the vicinity of 40K regular slides
>> and allows for great access.
>>
>> We used a lot of Eberbach single and quad cabinets (not all slides have
>> been transferred into the Delta cabinet yet). Other than wanting to move
>> away for the mess of having so many smaller wooden cabinets all over our
>> collections, we were also concerned with the long-term effect of acidic
>> vapour. A bryozoan collection originally housed in one of those now has
>> many specimens “suffering” from Bynesian Decay.
>>
>> Delta’s small slide cabinet version, as show on the webpage Dirk
>> indicated below, looks very interesting for smaller slide collections.
>>
>> Jean-Marc
>>
>>
>>
>> *Jean-Marc Gagnon*, Ph.D. (he/him/his) (il/lui)
>>
>> Curator, Invertebrate Collections / Chief Scientist / Director, Beaty
>> Centre for Species Discovery
>>
>> Conservateur, Collection des invertébrés / Expert scientifique en chef /
>> Directeur, Centre Beaty pour la découverte des espèces
>>
>> *Canadian Museum of Nature / Musée canadien de la nature*
>>
>>
>>
>> 613 364 4066
>>
>> 613 851-7556 cell
>>
>> 613 364 4027 Fax
>>
>> jmgagnon at nature.ca
>>
>> https://nature.ca/en/research-collections/science-experts/jean-marc-gagnon
>> <https://url.avanan.click/v2/___https://nature.ca/en/research-collections/science-experts/jean-marc-gagnon___.YXAzOmNhbGFjYWRlbXk6YTpnOmU5ODcwMDlhZDAyNjZmMTdjZGFiM2NjYTY0YmFhY2I3OjY6Y2QxMDpmNjY5ODYwZjM5Mzk1NTllYzY1MGU5YjliMmNiZGEyNGQxM2I4ZTZhNTI3YmFhZWMwNDM3N2YwNDk2MDcyMDFkOmg6VA>
>>
>>
>>
>> *Adresse postale / Postal Address:*
>>
>> Canadian Museum of Nature     / Musée canadien de la nature
>>
>> P.O. Box 3443, Sta. D   / Casier Postal 3443, Succ. D
>>
>> Ottawa, ON K1P 6P4                / Ottawa, ON K1P 6P4
>>
>> Canada                         / Canada
>>
>>
>>
>> *Adresse de livraison / Courier Address : *
>>
>> 1740 Pink Road, Gatineau, QC, J9J 3N7
>>
>>
>>
>>
>>
>> *From:* Nhcoll-l <nhcoll-l-bounces at mailman.yale.edu>
>> <nhcoll-l-bounces at mailman.yale.edu> *On Behalf Of *Dirk Neumann
>> *Sent:* Thursday, February 15, 2024 5:59 AM
>> *To:* nhcoll-l at mailman.yale.edu
>> *Subject:* [EXT]Re: [Nhcoll-l] [EXTERN] Microscope slide storage
>>
>>
>>
>> COURRIEL EXTERNE. Ne cliquez sur aucun lien ou pièce jointe à moins que
>> vous ne connaissiez l'expéditeur.
>>
>> EXTERNAL EMAIL. Do not click any links or attachments unless you know the
>> sender.
>>
>> Hi Vanessa,
>>
>>
>>
>> we are currently considering the Delta Design microslide cabinet:
>> https://www.deltadesignsltd.com/our-products/microslide-storage-2/
>> <https://url.avanan.click/v2/___https://www.deltadesignsltd.com/our-products/microslide-storage-2/___.YXAzOmNhbGFjYWRlbXk6YTpnOmU5ODcwMDlhZDAyNjZmMTdjZGFiM2NjYTY0YmFhY2I3OjY6NTE4Mjo0YzFhMzc4OThhYzhhNDY0YmRmOTBiMjA2ODFiYzQ0NTU3MmJlMzU3MGNlNDlmNmE5MzE5NjkwOWNmMmQ4OTg0Omg6VA>
>>
>>
>>
>> With best wishes
>>
>> Dirk
>>
>>
>>
>> Am 15.02.2024 um 10:40 schrieb Vanessa Pitusi:
>>
>> Hi all,
>>
>>
>>
>> Here at the Tromsø Museum, we are looking at new storage possibilities
>> for our microscope slides. I have been checking online for solutions, but
>> we have not found one that we have liked. Can anyone (especially in
>> Scandinavia or Europe) share what kind of storage/cupboard(s) they use and
>> where they were bought from.
>>
>>
>>
>> Thank you!
>>
>>
>>
>> Kind regards,
>>
>> Vanessa
>>
>>
>>
>>
>>
>>
>>
>>
>>
>>
>>
