Hi Tonya & Lennart,

I guess there are several layers to unfold here:

Foamed liners - like the F217 liners you mention - consist of a foamed
cell structure which - if the lid is screwed down tight - is compressed
again the neck of the jar. This outs the cells under pressure and closed
cells would withstand this tension better then open cell structures. It
is hard to tell if the F217 liners you mention has open or closed cells,
which gas is used for filling of the foam structure, etc. Even if the
F217 liners would have the right composition, right thickness, closed
cells - it still a is compressible gasket which has a limited life span.

To produce a good closure, you would further need to consider the
threads on the jar (continuous or not), the composition of the lid
itself (the best liner does not help if the plastic used for the lid
itself is of poor quality, etc. Most important seems to me that sizes of
such lids are standardised (rather then customised for specific jars),
so that they can easily be replaced if they fail. This is one of the
huge problems many collections with Copehagen jars now face after
plastic lids reached the end of their life span, sized where customised,
company went out of production: it is virtually impossible to replace
these lids - which causes huge problems in many collections.

It seems that F217 and PTFE liners are often used as inlays for Phenolic
caps (Bakelite) - which is a no-go in fluid collections because this
sort of thermoset plastics is easily degraded by residual formaldehyde
escaping from formaldehyde preserved specimens, even if they have been
transferred in to alcohol. As said: the best liner is worthless if the
plastic lid itself is unsuited.

In general, plastic lids are not a good oxygen barrier - this is also
worth remembering, especially if specimens inside such jars release a
lot of fats or oils.

Rather then concentrating on specific lids I would look into jars that
are designed for the pharmaceutical sector. Here, both the jar
(soda-lime glass) and the lid are expected (and usually tested) to
withstand a wide range of chemicals AND to provide a good barrier
against oxygen.

There are different suppliers of such jars, the disadvantage of the wide
mouth jars however is that the largest opening in these jars is 65 mm.
So a good option for for 100 - 1000 ml jars, but not for larger jars.
Stölzle (who also produce high quality borosilicate stoppered jars) is a
possible source for such jars, but there are many others as well:
https://pharma.stoelzle.com/en/product_category/weithalsglaser/

So as mostly no clear cut answer, but hopefully one that is useful.

All the best

Dirk




Am 20.11.2020 um 00:29 schrieb Haff, Tonya (NCMI, Crace):
>
> Hi all,
>
> I know I’ve asked about this before, but may I please clarify again….
> Does anyone have preference regarding PTFE (e.g. Teflon, I believe)
> lid liners vs F217 liners, which are layered polyethylene (as far as I
> understand). Can anyone give me advice as to what would be better as a
> lid liner for specimens kept in 70-90% EtOH? Advice very appreciated!
>
> Cheers,
>
> Tonya
>
> ---------------------------------------------------------
>
> Dr Tonya Haff
>
> Collections Manager
>
> Australian National Wildlife Collection
>
> National Research Collections Australia, CSIRO
>
> Canberra, Australia
>
> Phone: (+61) 02 6242 1566 (office)
>
> (+61) 0419 569 109 (mobile)
>
>
